ΡΕΛΕ ΙΣΧΥΟΣ LT1-F630A 230V 1ΝΟ

Technical characteristics:
– Operation class: АС3
– Rated operating voltage of power contactors: up to 1000V;50/60Hz
– Rated current: 115-800А
– Surge voltage wear resistance: >8000V
– Rated operating voltage of the coil: 12/24/36/48/110/230/400
– Electrical wear resistance (number of cycles): ≥10000000
– Mechanical wear resistance (number of cycles): ≥10000000
– Number of cycles (switching on) per hour: 200
– Power dissipation per pole: from 16 to 80W
– Ambient temperature: -10º ÷65ºС
– Maximum altitude: up to 2000м

Advantages:
– High reliability of the current parameters
– Secure separation of the power contacts
– Resistant to UV rays
– Easy mounting
– Long life

Functions:
– Frequently switching ON/OFF of electrical circuits under load
– Developing of systems for control of consumers
– Operational element in control boards
– Protection of loads and electrical devices in production and exploitation
– Control of motors in normal or heavy operating environments

Applications:
– Industry
– Building construction
– Administrative and public buildings

Mounting: On a DIN rail or using screws to a flat surface in a vertical position with maximum incline of ±5°

Standards: EN60947-1; EN60947-4-1; EMC
