ΡΕΛΕ CJ19-170 DPK 230V 170A

Technical characteristics of CJ19-43:
– Rated current: 32-170A
– Operation class: AC6
– Insulation voltage: 690V
– Rated operating voltage of the coil: 230V АC;50/60Hz
– Surge voltage wear resistance: >8000V
– Electrical wear resistance (number of cycles): ≥300000
– Mechanical wear resistance (number of cycles): ≥1000000
– Number of cycles (switching on) per hour: up to 600
– Number of the contacts :3 NO power contacts + 1 NO operative
– Leaking power: up to 13W
– Operating temperature: -10 to 65ºС
– Maximum altitude: 2000м

Advantages:
– Material: resistant to UV rays, self-extinguishing
– High reliability of the current parameters
– Secure separation of the power contacts
– Secure part of the contactor against contact with the consumer
– Manual switching on is not available

Functions:
– Switching on/off of capacitors for reactive energy compensation
– Developing of systems for compensation of reactive energy
– Lowering of peak transitional currents at switching on and switching off the capacitors

Applications:
– Industry
– Administrative and public buildings

Mounting: On DIN rail or using bolts to a flat surface in a vertical position with maximum gradient of ±5°

Standards: EN60947-1; EN60947-4-1; LVD; EMC
