ΤΕΡΜΑΤΙΚΟΣ ΔΙΑΚΟΠΤΗΣ CM-1705

Technical characteristics:
– Dielectric strength: 1000V AC
– Insulation resistance: 100mΩ min
– Contact resistance: 5mΩ
– Electrical wear resistance with active load (number of cycles): 500000
– Mechanical wear resistance (number of cycles): 5000000
– Operating speed: 0.1mm/s to 1.0 m/s
– Rated voltage: 230V
– IP code: IP65
– Fastening strenght of terminals: 6-8kgf/cm

Standards: EN60947-1; EN60947-5-1
